7.11 Upload/Download screen
On the Upload/Download screen, a user can write a set of parameter values to the drive
control or copy the current drive control parameters to the operator.
In order to use the Upload or Download functions, a user needs to have an existing dw5
le for the cong ID they want to interact with. To generate this le, the ‘CList’ function
should be used.
Key Function Bar Description
F1 Menu Return to File Menu screen
F2 CList
Generate new dw5 le of the current
CongID
F3 Upload Update the selected dw5 le’s values from
the inverter values
F4 Download Update inverter’s parameter values from the
saved values within the selected dw5
Figure 36: Upload/download screen
46
SCREEN OVERVIEW
