CP-Parameter
CP.31 Relay output 1 / Function (X2A.24...26)
CP.32 Relay output 2 / Function (X2A.27...29)
The switching level of CP.31 is 100,00. The switching level of CP.32 is CP.33!
Value Function
0 No function (generelly off)
1 Generelly on
2 Run signal; also by DC-braking
3 Ready signal (no error)
4 Fault relay
5 Fault relay (no auto-reset)
6 Warning or error message at abnormal stopping
7 Overload alert signal
8 Overtemperature alert signal power modules
9 External Overtemperature alert signal motor
11 Overtemperature alert signal interior OHI
12 Cable breakage 4...20 mA on analog input 1
14 Max. constant current (stall, CP.25) exceeded
15 Max. ramp current (LA-Stop CP.24) exceeded
16 DC-braking active
20 Actual value=set value (CP.3=Fcon, rcon; not at noP, LS error,SSF)
21 Accelerate (CP.3 = FAcc, rAcc, LAS)
22 Decelerate (CP.3 = FdEc, rdEc, LdS)
23 Real direction of rotation = set direction of rotation
24 Utilization (CP.6) > 100%
25 Active current > switching level
26 Intermediate circuit voltage (CP.7)>switching level
27 Real value (CP.1) > switching level
28 Set value (CP.2) > switching level
31 Absolut set value on AN1 > switching level
32 Absolut set value on AN2 > switching level
34 Set value on AN1 > switching level
35 Set value on AN2 > switching level
40 Hardware current limit activated
41 Modulation on
44 Inverter status (CP.3) = switching level
45 Power module temperatur > Level
46 Motor temperatur > Level
47 Ramp output frequency > Level
48 Apparent current (CP.4) > Level
49 Clockwise rotation (not at noP, LS, abnormal stopping, Fehler)
50 Counter clockwise (not at noP, LS, abnormal stopping, Fehler)
63 Absolut ANOUT1 > switching level
64 Absolut ANOUT2 > switching level
65 ANOUT1 > switching level
66 ANOUT2 > switching level
70 Driver voltage active (safety-relay)
73 Absolute active power > switching level
74 Active power > switching level
Unlisted values are only for application-mode.
