2-23
REINSTALL THE DOOR
1. Remove the 4 screws and 2 hinges from
the dryer door.
2. Replace the 4 screws in the same holes.
3. Remove the 4 screws from the opposite
side of the door.
4. Install the 2 hinges to the front panel of
the dryer using 4 screws. Use the non-
slotted side to attach the hinge to the
front panel.
5. Install screws in the top hinge holes in
the door. Do not tighten screws. Leave
approximately 1/4
˝ (5 mm) of screw ex-
posed.
A. Install these screws first.
A
A
6. Hang door by placing screw heads into
top slotted holes of hinges and slide door
down. Align bottom screw holes in hinge
and door. Install two bottom screws.
Tighten all hinge screws.
7. Close door to engage door strike.
To Next Page
