4-5
REMOVING THE MOISTURE SENSOR
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug dryer or disconnect power.
2. Turn off gas supply to dryer.
3. Open the dryer door and remove the lint
filter screen.
6. From inside the dryer, remove the two
screws from the outlet grille.
7. Pull the outlet grille and moisture sensor
away from the dryer and disconnect the
black and yellow-red wires from the sen
-
sor strips.
4. Remove the cabinet front (see page 4-6
for the procedure).
Lint Filter Screen
Moisture Sensor
Connector
Outlet Grille
Screws
Moisture Sensor
Wires
5. Disconnect the moisture sensor connec-
tor from the harness connector.
Moisture Sensor
Moisture Sensor Strips
To Next Page
