Kenwood TK-2170 User Manual

14
PROGRAMMABLE FUNCTIONS
The Auxiliary, Side 1, Side 2, S, A, <B, and C> keys {pages 11
and 12} can be programmed with the functions below. Please
contact your dealer for further details on these functions.
Note:
◆ The selector can be programmed as either CH/GID Up/Down or
Zone Up/Down.
◆ Your dealer can also enable the selector to be used when making
setting adjustments (as an optional method for using the <B and
C> keys).
• Autodial
• Autodial Programming
• AUX
• Call 1 ~ 2
• CH/GID Down
• CH/GID Up
• Channel Entry
• Digit 1x Down
1
• Digit 1x Up
1
• Digit 10x Down
1
• Digit 10x Up
1
• Direct CH/GID 1 ~ 4
• Display Character
• Emergency
2
• Home CH/GID
• Key Lock
• Lamp
• Lone Worker
• Low Transmit Power
• Monitor
• Monitor Momentary
• None
• OST
• Scan
• Scan Delete/Add
• Scrambler
• Selcall
• Selcall + Status
• Squelch Level
• Squelch Off
• Squelch Off Momentary
• Status
•Talk Around
•Transceiver Password
•Trunking Group Code Select
3
• VOX
• Zone Down
• Zone Up
1
“Digit 1x Down”, “Digit 1x Up”, “Digit 10x Down”, and “Digit 10x Up” can
be programmed only when the 5-tone function has been enabled.
2
“Emergency” can be programmed only on the Auxiliary (orange) key.
3
“Trunking Group Code Select” is available only when the Trunking
board has been installed.

Kenwood TK-2170 Specifications

General Specifications

frequency range	136~174MHz
number of channels	Max. 128 per radio
channel spacing	Wide: 25, 30kHz; Narrow: 12.5, 15kHz
battery voltage	7.5V DC ± 20%
antenna impedance	50Ω
channel frequency spread	38MHz

Battery

battery life with KNB-24L (1400mAh)	9 hours
battery life with KNB-25A (1200mAh)	8 hours
battery life with KNB-26N (2000mAh)	12 hours
battery life with KNB-35L (1950mAh)	11 hours

Operating Environment

operating temperature range	–22°F~+140°F (–30°C~+60°C)
frequency stability	± 0.00025% (–22°F~+140°F)

Receiver

sensitivity (12dB SINAD) Wide	0.25µV
sensitivity (12dB SINAD) Narrow	0.28µV
selectivity Wide	70dB
selectivity Narrow	65dB
intermodulation distortion Wide	65dB
intermodulation distortion Narrow	60dB
spurious response	65dB
audio output (8Ω impedance)	500mW with less than 5% distortion

Transmitter

RF power output HI	5W
RF power output LO	1W
spurious response	70dB
modulation Wide	16K0F3E
modulation Narrow	11K0F3E
FM hum & noise Wide	45dB
FM hum & noise Narrow	43dB
audio distortion W/N	Less than 5%

Weight and Dimensions

weight with battery, antenna, and beltclip	12.0 oz. (340 g)
dimensions with KNB-24L or 35L battery	56 x 109 x 31.7 mm
dimensions with KNB-25A or 26N battery	56 x 109 x 37.9 mm
