Kenwood TK-2170 User Manual

40
BACKGROUND OPERATIONS
TIME-OUT TIMER (TOT)
The purpose of the Time-out Timer is to prevent any caller
from using a channel for an extended period of time.
If you continuously transmit for a period of time that exceeds
the programmed time set by your dealer (default is 1 minute),
the transceiver will stop transmitting and an alert tone will
sound. To stop the tone, release the PTT switch.
Your dealer can program the TOT time in the range of
15 seconds to 20 minutes.
BUSY CHANNEL LOCKOUT (BCL)
When activated, BCL prevents you from interfering with other
parties who may be using the same channel that you
selected. Pressing the PTT switch while the channel is in use
will cause your transceiver to emit an alert tone and
transmission will be inhibited (you cannot transmit). Release
the PTT switch to stop the tone and return to receive mode.
Note: Ask your dealer for an explanation on how BCL functions
when using QT, DQT, DTMF, 5-tone, or FleetSync signaling.
BATTERY SAVER
If activated by your dealer, the Battery Saver function will
decrease the amount of power used when a signal is not
being received and no operations are being performed (no
keys are being pressed, and no switches are being turned).
While the channel is not busy and no operation is performed for
5 seconds, Battery Saver turns ON. When a signal is received
or an operation is performed, Battery Saver turns OFF.
Note: While the Battery Saver is operating, the LED may flash green
when receiving a QT/DQT signal which does not match the QT/DQT
tone/code set up in your transceiver.

Kenwood TK-2170 Specifications

General Specifications

frequency range	136~174MHz
number of channels	Max. 128 per radio
channel spacing	Wide: 25, 30kHz; Narrow: 12.5, 15kHz
battery voltage	7.5V DC ± 20%
antenna impedance	50Ω
channel frequency spread	38MHz

Battery

battery life with KNB-24L (1400mAh)	9 hours
battery life with KNB-25A (1200mAh)	8 hours
battery life with KNB-26N (2000mAh)	12 hours
battery life with KNB-35L (1950mAh)	11 hours

Operating Environment

operating temperature range	–22°F~+140°F (–30°C~+60°C)
frequency stability	± 0.00025% (–22°F~+140°F)

Receiver

sensitivity (12dB SINAD) Wide	0.25µV
sensitivity (12dB SINAD) Narrow	0.28µV
selectivity Wide	70dB
selectivity Narrow	65dB
intermodulation distortion Wide	65dB
intermodulation distortion Narrow	60dB
spurious response	65dB
audio output (8Ω impedance)	500mW with less than 5% distortion

Transmitter

RF power output HI	5W
RF power output LO	1W
spurious response	70dB
modulation Wide	16K0F3E
modulation Narrow	11K0F3E
FM hum & noise Wide	45dB
FM hum & noise Narrow	43dB
audio distortion W/N	Less than 5%

Weight and Dimensions

weight with battery, antenna, and beltclip	12.0 oz. (340 g)
dimensions with KNB-24L or 35L battery	56 x 109 x 31.7 mm
dimensions with KNB-25A or 26N battery	56 x 109 x 37.9 mm
