TP-6805 8/15 77Section 5 Troubleshooting
5.12 Status Messages
The messages shown in Figure 5-15 and Figure 5-16
are displayed to show system status. Notices are
displayed in the Event History in SiteTech when active
but do not appear on the controller display. Some status
messages are displayed when a digital input is
activated; the optional Programmable Interface Module
(PIM) is required for display of those messages as noted
in the table.
Most status messages indicate normal system
operation and do not require action unless the generator
is not operating correctly.
Status Message Action Description/ Comments Check
Always Off * Notice
OnCue Plus has been used to control
this PIM digital output. The digital output
is no longer controlled by the generator
set.
Applies to digital outputs B3 through B6
on the PIM only.
Click on the PIM output in
OnCue Plus to turn the output
on or off. See the OnCue
Plus Operation Manual.
To reset the PIM digital output
to a function controlled by the
generator set, use SiteTech
software to re-ass ign the
output event.
Always On * Notice
Auto Locked *
(Chicago Code Active)
Notice The digital output for Chicago Code
Active (PIM) is active (contacts closed),
indicating the digital input for Chicago
Code Active (PIM) is active (low) and
thus master switch is locked in the AUTO
position.
Check customer equipment
connected to the PIM module.
Common Fault Notice The digital output for Common Fault
(PIM) is active (contacts closed),
indicating the generator is shutdown for
any (all) fault.
Check for faults and
troubleshoot any/all fault
conditions individually.
Common Warng Notice The digital output for Common Warning
(PIM) is active (contacts closed),
indicating that any (all) warning is active.
Check for warnings and
troubleshoot any/all warning
conditions individually.
Emerg Pwr On
(Emergency Power System
Supplying Load)
Notice The digital output for EPS Supplying
Load (PIM) is active (contacts closed),
indicating there is current output (>5%)
from the alternator, only if CTs are
installed.
—
Eng Cooldown Notice The digital output for Engine Cooldown
Active (PIM) is active (contacts closed),
indicating the generator is running in
cooldown. (Delay 5 min.)
Check remote start circuit if it
was expected that the
generator should be running.
Consult ATS operations
manual.
Fuel Spill * Notice The digital output for Fuel Spill (PIM) is
active (contacts closed), indicating any of
the digital inputs for Fuel Tank Leak
Warning, Fuel Tank Leak Shutdown,
Engine Fuel Level Warning or Engine
Fuel Level Critically High (PIM) is active
(low).
Check customer equipment
that is connected to the Fuel
Tank Leak Warning, Fuel Tank
Leak Shutdown, Engine Fuel
Level Warning or Engine Fuel
Level Critically High input on
the PIM.
* Programmable Interface Module (PIM) required.
] A load management device is an LCM, load shed kit, or RXT combined interface/ load management board.
[ Load management device required.
