Kohler 20EFOZ Service Manual

TP-6071 3/004 Section 1 Specifications
1.5 Generator, 4 Lead
Component Specification
13EOZ
11EFOZ
15.5EOZ
13EFOZ
20--23EOZ
16--19EFOZ
Hot exciter field voltage/amperage readings at rated voltage
No load (63 Hz) 4/0.7 4/0.7 6/1.0
Full load (60 Hz) 12/1.8 14/2.3 16/2.4
Exciter field resistance (cold) 5.8 5.8 5.8
Exciter armature resistance (cold) 0.5 0.5 0.5
Main field (rotor) resistance (cold) 4.3 2.9 3.0
Stator output voltages with separately excited generator, using 12-volt battery (60 Hz only)
1--2, 3--4, 33--44 135 135 95
55--66 180 180 125
B1-B2 17 17 12
Cold stator resistance, ohms
1--2, 3--4, (V1--V4) 0.12 0.12 0.07
55--66 1.5 1.5 1.3
B1-B2 0.07 0.07 0.06
1.6 Generator, 12 Lead
Component Specification
14EOZ
11.5EFOZ
20--24EOZ
17.5--20EFOZ
Hot exciter field voltage/amperage readings at rated voltage
No load (63 Hz) 6/0.9 8/1.4
Full load (60 Hz) 17/2.6 16/2.4
Exciter field resistance (cold) 5.5 5.8
Exciter armature resistance (cold) 0.5 0.5
Main field (rotor) resistance (cold) 4.3 3.0
Stator output voltages with separately excited generator, using 12-volt battery (60 Hz only)
1--4, 2--5, 3--6, 7--10, 8--11, 9--12, V1--V2 110 70
55--66 125 90
B1-B2 12 9
Cold stator resistance, ohms
1--2, 3--4, (V1--V4) 0.06 0.04
55--66 1.5 1.3
B1-B2 0.06 0.05
