TP-6071 3/00 53Section 10 Wiring Diagrams
10.5 Remote Start and Four-Meter
Panel
Start
P
P
7C
K1
70
47
43
N
Hourmeter
DC voltmeter
Oil pressure
gauge
Water temp.
gauge
Gen. ON light
Remote
switch
5
P3-5
P3-6
P3-1
P3-2
P3-3
P2-3
P2-7
P2-8 P2-9
P4-2 P4-3
K2
P1-14
47
P2-4
43
P2-5 P2-6
N
P1-9
N
+--
Relay
circuit
board
Local
switch
Violet
Tan
Black
Yellow/
Red
Grey/
Black
L. Blue
Start
Stop
Stop
P3-4
W.T.
sender
J3-4 J3-5
J3-6
J3-1 J3-2 J3-3
O.P.
sender
10-amp
fuse
TP-5588-7
