SEN03766-02 00 Index and foreword
8
PC130-8
3. Filing method
File by the brochures in the correct order of the form number printed in the shop manual composition
tab
le.
q
Revised edition mark
When a manual is revised, the ones and tens digits of the form number of each brochure is
incr
eased by 1. (Example: 00, 01, 02 …)
q
Revisions
Revised brochures are shown in the shop manual composition table.
4. Symbols
Important safety and quality portions are marked with the following symbols so that the shop manual will
be
us
ed practically.
5. Units
In this shop manual, the units are indicated with International System of units (SI). For reference, con-
ventionally used Gravitational System of units is indicated in parentheses { }.
Symbol Item Remarks
k
Safety Special safety precautions are necessary when performing work.
a Caution
Special technical precautions or other precautions for preserving stan-
dards are necessary when performing work.
4
Weight
Weight of parts of component or parts. Caution necessary when
selec
ting hoisting wire, or when working posture is important, etc.
3
Tightening
tor
que
Places that require special attention for tightening torque during
assembly.
2
Coat Places to be coated with adhesives, etc. during assembly.
5
Oil, coolant Places where oil, etc. must be added, and capacity.
6
Drain Places where oil, etc. must be drained, and quantity to be drained.
To Next Page
