50 Disassembly and assembly SEN04130-01
PC130-8
3
10. Remove mounting bolts and lift off center
swivel joint assembly (20). [*1]
a Sling the
joint assembly temporarily, then
remove the bolts.
4 Center swivel joint assembly: 30 kg
Installation
q Installation is performed in the opposite way to
removal.
[*1]
5 Hydraulic tank: 90 l
(Specified quantity of oil): 14
5 l
2 Mounting bolt screw:
Liquefied adhesive (LT-2)
3 Mounting bolt:
98.1 – 123.0 Nm {10.0 – 12.5 kgm}
q Bleeding air
Bleed air from the swing motor. For details,
se
e Testing and adjusting, "Bleeding air from
each part".
