• (A): Turning FORWARD LEFT
Push the right travel lever forward.
The machine turns forward LEFT.
• (B): Turning REVERSE LEFT
Push the right travel lever backward.
The machine turns in reverse LEFT.
REMARK
When turning to the RIGHT, read the preceding procedure by
replacing the word "LEFT" with "RIGHT", then operate the left
travel lever.
CHANGE DIRECTION OF MACHINE
When turning LEFT during straight travel
• (A): Forward left turn
Return the left travel lever from FORWARD to NEUTRAL
position.
The machine turns forward LEFT.
• (B): Reverse left turn
Return the left travel lever from REVERSE to NEUTRAL
position.
The machine turns in reverse LEFT.
REMARK
When turning to the forward RIGHT, return the right travel lever
from FORWARD to NEUTRAL position. When turning to the re-
verse RIGHT, return the right travel lever from REVERSE to
NEUTRAL position.
MACHINE OPERATIONS AND CONTROLS OPERATION
3-192
