(1) 2-Piece Boom control pedal
(A) Retract second boom raise cylinder
(B) Extend second boom raise cylinder
(A) Press the rear of the pedal
9JH02584E
A
B
KS001275
ATTACHMENTS AND OPTIONS 2-PIECE BOOM
6-15
