* to top of counterweight
KS000657
Track shoe (mm)
PC210LC-11 (15m Super Long Front)
Operating weight (kg)
Ground pressure (kg/cm
2
)
600mm 23470 0.49
700mm 23740 0.43
800mm 24060 0.38
900mm 24330 0.34
Working range Unit PC210LC-11 (15m Super Long Front)
Max Digging Reach (to bucket teeth) mm 15435
NOTICE
Specifications are subject to change without notice.
Working ranges
Unit PC210LC-11 (15m Super Long Front)
A Maximum digging height mm 13977
B Maximum dumping height mm 11238
C Maximum digging depth mm 14635
D Maximum digging reach mm 11790
G Maximum digging reach at ground level mm 15435
H Minimum swing radius* mm 15339
ATTACHMENTS AND OPTIONS SUPER LONG FRONT BOOM AND ARM
6-33
