(If equipped)
Replace the teeth before they wear down as far as the adapter.
1. Raise the bucket to a suitable height, then put blocks under the bucket to prevent the bucket from coming down.
Raise the bucket so that the bottom surface of the bucket is horizontal.
2.
Remove pin (2) installed to the bucket, then remove tooth (1).
Put a rod (slightly narrower than the pin) in contact with the
hatched portion (either left or right) and tap pin (2) out to the
opposite side.
3.
Fit new tooth (1) in adapter (3), push in pin (2) partially by hand,
then knock it in with a hammer.
4.
After operating the machine for a few hours, check that the pin
does not come out.
