VM-218DTxr, VM-218DT – Technical Specifications
36
Technical Specifications
Inputs
1 HDMI
On a female HDMI connector
1 HDBT
On an RJ-45 connector
Outputs
1 HDMI
On a female HDMI connector
8 HDBT
On RJ-45 connector
1 Unbalanced Stereo Audio
On a 3.5mm mini jack
Ports
1 IR IN
On a 3.5mm mini jack for IR link extension via
IN 2 HDBT
8 IR OUT
On 3.5mm mini jacks for IR link extension via
OUT HDBT (2 to 9)
1 RS-232 IN
On a 3-pin terminal block for serial link
extension via IN 2 HDBT
8 RS-232 OUT
On 3-pin terminal blocks for serial link
extension via OUT HDBT (2 to 9)
1 Mini USB
On a female USB connector for firmware
upgrade
1 RS-232
On a 3-pin terminal block for device control
1 10/100BaseT Ethernet
On an RJ-45 female connector for device
control via LAN and Ethernet link extension
via IN HDBT and OUT HDBT (2 to 9)
Extension Reach
VM-218DTxr
4K @60Hz (4:2:0)
Up to 100m (330ft)
Full HD (1080p @60Hz 36bpp)
Up to 130m (430ft)
HDBaseT Ultra Mode and Full HD
(1080p @60Hz 24bpp)
Up to 180m (590ft)
VM-218DT
4K @60Hz (4:2:0)
Up to 40m (130ft)
Full HD (1080p @60Hz 36bpp)
Up to 70m (230ft)
Compliance
HDBaseT 1.0
Video
Max. Resolution
4K@60Hz (4:2:0) and 4K@30Hz (4:4:4)
Compliance
Supports HDMI 2.0 and HDCP 1.4
RS-232 Extension
Baud Rate
300 to 115,200
Analog Audio
Max Level
1 Vrms
THD + Noise
0.03% @1kHz at nominal level
Controls
Front Panel
Front panel buttons: input select, volume,
EDID, IR
Indication LEDs: input select, EDID type,
outputs
Rear Panel
RS-232 device control
RS-232 remote control via HDBT ports
IR remote control via HDBT ports
Ethernet
DIP-switches
Power
Consumption
65VA
Source
100-240V AC, 50/60Hz
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE, FCC
Environmental
RoHs, WEEE
