Caution
Omega
49
Correlation between tightening torques, dimension P and clearance S
1
N-EUPEX N-EUPEX-DS Tightening torque T
A
and width across flats S
W
for bolts
to DIN 912 Part 2/3
coupling coupling
Size Siz e T
A
S
W
P S
1
Nm [mm] [mm] [mm]
110 118 14 6 33 2-4
125 135 17,5 6 38 2-4
140 152 29 8 43 2-4
160 172 35 8 47 2-5
180 194 44 8 50 2-6
200 218 67,5 10 53 2-6
225 245 89 10 61 2-6
250 272 145 14 69 3-8
280 305 185 14 73 3-8
315 340 200 14 78 3-8
350 350 260 17 83 3-8
400 430 340 17 88 3-8
440 472 420 17 99 5-10
480 514 550 19 104 5-10
520 556 670 19 115 5-10
560 -- -- 710 19 125 6-12
610 -- -- 1450 22 135 6-12
660 -- -- 1450 22 145 6-12
710 -- -- 1450 22 155 6-12
Commissioning the coupling
Measures to be taken prior to commissioning
Before commissioning the coupling check the proper installa-
tion of the flexible coupling elements, i.e. make sure the flexi-
bles are flush with the hub face, and check whether the set
screws are properly tightened. Also verify coupling alignment
and clearance S
1
and correct, if necessary. Check whether all
screwed connections have been tightening with the tightening
torques specified. Finally, fit the coupling guard against acci-
dental contact.
Operation
General operating data
During coupling operation, watch out for
· changed running noises,
· sudden vibrations.
If any irregularities occur during operation,
switch off the driver immediately and refer
to the trouble--shooting table to determine the cause.
The trouble--shooting table lists possible faults, causes and
suggested remedies.
