SERVICE WORK ON THE CHASSIS 13
191
Guideline
Nut, rear wheel
spindle
M25x1.5 90 Nm (66.4 lbf ft)
Thread greased
Info
Chain adjusters
4
can be turned by 180°.
Finishing work
– Remove the vehicle from the center stand. ( p. 182)
13.11 Checking the chain, rear sprocket, and engine sprocket
Preparatory work
– Raise the vehicle with the center stand. ( p. 181)
100132-10
Main work
– Check the rear sprocket and engine sprocket for wear.
» If the rear sprocket and engine sprocket are worn:
– Change the drivetrain kit.
Info
The engine sprocket, rear sprocket and chain
should always be replaced together.
