16 ELECTRICAL SYSTEM

270

16.11 Diagnostics connector

H02029-10

Diagnostics connector

is located under the front rider's seat.

16.12 Front ACC1 and ACC2

P00174-10

Installation location

–

The front power supplies ACC1

and ACC2

are located

behind the headlight.

Info

The power supplies are protected by a fuse, however this

fuse also protects other power consumers.

The maximum continuous load is therefore significantly

lower than the value of the fuse.

Do not use a stronger fuse.
