STORAGE 21

297

21.2 Preparing for use after storage

401059-01

– Remove the vehicle from the center stand. ( p. 182)

– Install the battery. ( p. 252)

Info

If the battery was removed, the time and date must be

set.

– Perform checks and maintenance measures when preparing for

use. ( p. 152)

– Take a test ride.
