21 TECHNICAL DATA 104
Static sag 40 mm (1.57 in)
Riding sag 110 mm (4.33 in)
Fitted length 477 mm (18.78 in)
Shock absorber oil Shock absorber fluid (SAE 2.5) (50180751S1) ( p. 107)
21.8.3 XC‑F US
Shock absorber article number 18.18.7P.75
Shock absorber WP Performance Systems 5018 DCC Link
Compression damping, low-speed
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Compression damping, high-speed
Comfort 2.5 turns
Standard 2 turns
Sport 1.5 turns
Rebound damping
Comfort 17 clicks
Standard 15 clicks
Sport 13 clicks
Spring preload 7 mm (0.28 in)
Spring rate
Weight of rider: 65… 75 kg (143… 165 lb.) 42 N/mm (240 lb/in)
Weight of rider: 75… 85 kg (165… 187 lb.) 45 N/mm (257 lb/in)
Weight of rider: 85… 95 kg (187… 209 lb.) 48 N/mm (274 lb/in)
Spring length
Weight of rider: 65… 75 kg (143… 165 lb.) 245 mm (9.65 in)
Weight of rider: 75… 85 kg (165… 187 lb.) 245 mm (9.65 in)
Weight of rider: 85… 95 kg (187… 209 lb.) 247 mm (9.72 in)
Gas pressure 10 bar (145 psi)
Static sag 40 mm (1.57 in)
Riding sag 110 mm (4.33 in)
Fitted length 477 mm (18.78 in)
Shock absorber oil Shock absorber fluid (SAE 2.5) (50180751S1) ( p. 107)
21.9 Chassis tightening torques
Screw air intake temperature sensor EJOT DELTA PT
®
45x12‑Z 2 Nm (1.5 lbf ft) –
Screw, air filter box cover EJOT PT
®
K60x20-Z 3 Nm (2.2 lbf ft) –
Screw, pressure regulator EJOT PT
®
K60x25‑Z 3 Nm (2.2 lbf ft) –
Screw, fixed grip M4 5 Nm (3.7 lbf ft) Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft) –
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft) –
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –
Screw, frame protector M5 3 Nm (2.2 lbf ft) –
Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, chain sliding guard M6 6 Nm (4.4 lbf ft) Loctite
®
243™
