WIRING DIAGRAM 125
Components
A6 CDI controller
B3 Wheel speed sensor
G1 Battery
G2 Alternator
H1 Right rear turn signal
H2 Left front turn signal
H3 Left rear turn signal
H4 Right front turn signal
H5 Brake/tail light
H7 Parking light
H9 License plate lamp
H11 Low/high beam
H13 Horn
H15 Turn signal indicator light
H18 High beam indicator light
K1 Starter relay with main fuse
K2 Turn signal relay
L1 Ignition pulse generator
L2 Ignition coil
M1 Starter motor
N2 Voltage regulator/rectifier
P1 Speedometer
S1 Rear brake light switch
S2 Front brake light switch
S5 Tripmaster switch (optional)
S6 Light switch
S7 Horn button, short circuit button
S8 Turn signal switch
S10 Electric starter button
S11 Emergency OFF switch (EXC OFF)
Cable colors
bl Black
bl-wh Black-white
br Brown
br-bl Brown-black
bu Blue
bu-wh Blue-white
gn Green
gr Gray
or Orange
pu Violet
re Red
re-bl Red-black
re-wh Red-white
wh White
wh-gn White-green
wh-re White-red
ye Yellow
ye-bl Yellow-black
ye-re Yellow-red
