OPERATING ELEMENTS 12
Shift lever
400204-12
The shift lever is mounted on the left side of the engine.
400204-11
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
Foot brake pedal
400205-10
The foot brake pedal is located in front of the right footrest and operates the rear
wheel brake.
Plug-in stand
500180-10
Note
Danger of damageಗDanger of damage by the vehicle running away or falling over.
ಥ Always place the vehicle on a firm and even surface.
To stand the motorcycle, plug the plug-in stand
into the left side of the wheel spin-
dle.
Info
Before riding, remove the plug-in stand.
