TECHNICAL
DATA
-
CARBURETOR
73
7(&+1,&$/
'$7$
&$5%85(725
Carburetor
type
KEIHIN
FCR-MX
41
Carburetor
identfication
number
4125I
Needle
position
4th
position
from
top
Idle
mixture
adjusting
screw
Open
1.5
turns
Pump
membrane
stop
2.15
mm
(0.08
in)
Hot
start
button
Diameter
of
bore
in
carburetor
body
2.5
mm
(0.1
in)
Main
jet
185
Jet
needle
OBDTR
Idling
jet
42
Main
air
jet
200
Idle
air
jet
100
Cold
start
jet
85
Throttle
slide
15
74
76
