TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 78
7(&+1,&$/ '$7$  &+$66,6 7,*+7(1,1* 72548(6
Spoke nipple, front wheel M4,5 5Nm (3.69lbfft) ಥ
Spoke nipple, rear wheel M5 5Nm (3.69lbfft) ಥ
Remaining nuts, chassis M6 15Nm (11.06lbfft) ಥ
Remaining screws, chassis M6 10Nm (7.38lbfft) ಥ
Screw, rear brake disc M6 14Nm (10.33lbfft) ಥ
Screw, front brake disc M6 14Nm (10.33lbfft) ಥ
Screw, shock absorber adjusting ring M6 5Nm (3.69lbfft) ಥ
Screw, ball joint of push rod on foot-
brake cylinder
M6 10Nm (7.38lbfft) ಥ
Nut, rear sprocket screw M8 35Nm (25.82lbfft) Loctite
®
243™
Nut, rim lock M8 10Nm (7.38lbfft) ಥ
Remaining nuts, chassis M8 30Nm (22.13lbfft) ಥ
Remaining screws, chassis M8 25Nm (18.44lbfft) ಥ
Screw, top triple clamp M8 17Nm (12.54lbfft) ಥ
Screw, bottom triple clamp M8 12Nm (8.85lbfft) ಥ
Screw, fork stub M8 15Nm (11.06lbfft) ಥ
Screw, top steering stem M8 17Nm (12.54lbfft) Loctite
®
243™
Screw, handlebar clamp M8 20Nm (14.75lbfft) ಥ
Screw, engine brace M8 33Nm (24.34lbfft) ಥ
Screw, subframe M8 35Nm (25.82lbfft) Loctite
®
243™
Screw, front brake caliper M10x1,25 40Nm (29.5lbfft) Loctite
®
243™
Engine carrying screw M10 60Nm (44.26lbfft) ಥ
Remaining nuts, chassis M10 50Nm (36.88lbfft) ಥ
Remaining screws, chassis M10 45Nm (33.19lbfft) ಥ
Screw, handlebar support M10 40Nm (29.5lbfft) Loctite
®
243™
Nut, seat fixing M12x1 20Nm (14.75lbfft) ಥ
Screw, top shock absorber M12 80Nm (59.01lbfft) Loctite
®
243™
Screw, bottom shock absorber M12 80Nm (59.01lbfft) Loctite
®
243™
Nut, swingarm pivot M16x1,5 100Nm (73.76lbfft) ಥ
Screw-in nozzles, cooling system M20x1,5 12Nm (8.85lbfft) Loctite
®
243™
Nut, rear wheel spindle M20x1,5 80Nm (59.01lbfft) ಥ
Screw, top steering head M20x1,5 10Nm (7.38lbfft) ಥ
Screw, bottom steering head M20x1,5 60Nm (44.26lbfft) Loctite
®
243™
Screw, front wheel spindle M24x1,5 40Nm (29.5lbfft) ಥ
