TECHNICAL DATA 22
131
22.4 Chassis
Frame Central tube frame made of chrome molybdenum steel
tubing
Fork WP XACT 5548
Suspension travel
front 310 mm (12.2 in)
rear 300 mm (11.81 in)
Fork offset 22 mm (0.87 in)
Shock absorber WP XACT 5750
Brake system Disc brakes, floating brake calipers
Brake discs - diameter
front 260 mm (10.24 in)
rear 220 mm (8.66 in)
Brake discs - wear limit
front 2.5 mm (0.098 in)
rear 3.5 mm (0.138 in)
Offroad tire pressure
front 1.0 bar (15 psi)
rear 1.0 bar (15 psi)
Secondary ratio (All SX‑F models) 13:49
Secondary ratio (XC‑F US) 13:48
Chain 5/8 x 1/4"
Rear sprockets available 45, 47, 48, 49, 50, 51, 52
Steering head angle 63.9°
Wheelbase 1,485 ± 10 mm (58.46 ± 0.39 in)
Ground clearance, unloaded 370 mm (14.57 in)
Seat height, unloaded 950 mm (37.4 in)
Weight without fuel, approx. (SX‑F EU) 100 kg (220 lb.)
Weight without fuel, approx. (SX‑F US) 100.5 kg (221.6 lb.)
Weight without fuel, approx. (XC‑F US) 101 kg (223 lb.)
Maximum permissible front axle load 145 kg (320 lb.)
Maximum permissible rear axle load 190 kg (419 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
22.5 Electrical system
12 V battery HJTZ5S-FP-C Lithium-ion battery
Battery voltage: 12 V
Nominal capacity: 2.0 Ah
Maintenance-free
Fuse 58011109110 10 A
Malfunction indicator lamp LED
Remaining indicator lamps
(XC‑F US)
W2.3W / socket W2x4.6d 12 V
2.3 W
