KTM 450 SX-F CAIROLI 2020 User Manual

SERVICE WORK ON THE CHASSIS 11
63
11.21 Mounting the seat
H02218-11
– Mount the front of the seat on the collar bushing of the fuel
tank, lower the seat at the rear, and push the seat forward.
F01533-10
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
11.22 Removing the air filter box cover
Condition
The air filter box cover is secured.
– Remove the seat. ( p. 62)
F01534-10
–
Remove screw
1
.
F01534-11
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
