6 CONTROLS
16
6.5 Electric starter button
S01195-10
The electric starter button
1
is fitted on the right side of the
handlebar.
Possible states
• Electric starter button in basic position
• Electric starter button is pressed – In this position, the
starter motor is actuated.
6.6 Combination switch
H02887-01
The combination switch is fitted on the left side of the handlebar.
Possible states
1 STANDARD – STANDARD mapping is activated when
LED 1 lights up.
1TC STANDARD with TC – STANDARD mapping with trac-
tion control is activated when LED 1 and TC light up.
2 ADVANCED – ADVANCED mapping is activated, when
LED 2 lights up.
2TC ADVANCED with TC – ADVANCED mapping with trac-
tion control is activated when LED 2 and TC light up.
The engine characteristic can be changed using button MAP on the
combination switch.
The launch control and the traction control can also be activated
using the combination switch.
6.7 Overview of indicator lamps
F01577-10
Possible states
Malfunction indicator lamp lights up/flashes orange
– The OBD has detected an error in the vehicle elec-
tronics.
Malfunction indicator lamp flashes orange rapidly
– Launch control is activated.
(XC‑F US)
Fuel level warning lamp lights up orange – The fuel
level has reached the reserve mark.
