TECHNICAL DATA 23
157
23.2 Engine tightening torques
Oil jet, piston cooling M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Crankshaft speed sensor screw and
cable retainer
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil nozzle for clutch lubrication M5 2.5 Nm (1.84 lbf ft)
Oil nozzle for piston cooling M5 2.5 Nm (1.84 lbf ft)
Oil nozzle for rocker arm lubrica-
tion
M5 2.5 Nm (1.84 lbf ft)
Oil nozzle for timing chain lubrica-
tion
M5 2.5 Nm (1.84 lbf ft)
Screw, bearing retainer M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, clutch spring retainer M5 6 Nm (4.4 lbf ft)
Screw, gear position sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
2701™
Screw, suction pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, water pump impeller M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 10 Nm (7.4 lbf ft)
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fuel vapor retention system
connection
M6 5 Nm (3.7 lbf ft)
Loctite
®
2701™
Screw, fuel vapor retention system
lock
M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft)
Screw, pressure pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, timing chain clip M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain tensioner M6 10 Nm (7.4 lbf ft)
Screw, timing chain tensioning rail M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
