23 TECHNICAL DATA
158
Screw, torque governor M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft)
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Oil nozzle for conrod bearing lubri-
cation
M6x0.75 2.5 Nm (1.84 lbf ft)
Plug, oil channel M7 9 Nm (6.6 lbf ft)
Loctite
®
243™
Screw, camshaft retaining bracket M7x1 15 Nm (11.1 lbf ft)
Screw, rocker arm bearing M7x1 15 Nm (11.1 lbf ft)
Crankshaft clamp screw plug M8 10 Nm (7.4 lbf ft)
Plug, timing chain tensioner M8 8 Nm (5.9 lbf ft)
Plug, oil channel M10 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Spark plug M10x1 10 … 12 Nm (7.4 … 8.9 lbf ft)
Engine coolant temperature sensor M10x1.25 12 Nm (8.9 lbf ft)
Screw, cylinder head M10x1.25 1st stage
10 Nm (7.4 lbf ft)
2nd stage
30 Nm (22.1 lbf ft)
3rd stage
50 Nm (36.9 lbf ft)
Collar and thread oiled
Nut, rotor M12x1 60 Nm (44.3 lbf ft)
Thread, oiled with engine oil/cone
degreased
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Screw plug, oil pressure control
valve
M12x1.5 20 Nm (14.8 lbf ft)
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear wheel M20LHx1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Screw plug, oil screen M20x1.5 15 Nm (11.1 lbf ft)
23.3 Capacities
23.3.1 Engine oil
Engine oil 1.2 l (1.3 qt.) Engine oil (SAE 10W/50)
( p. 164)
23.3.2 Coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 164)
23.3.3 Fuel
Total fuel tank capacity, approx.
(All EU models)
9 l (2.4 US gal) Super unleaded (ROZ 95)
( p. 165)
