CONTROLS 6
19
6.11 Combination switch (EXC-F SIX DAYS, XCF-W)
H02887-01
The combination switch is fitted on the left side of the handlebar.
Possible states
1 STANDARD – STANDARD mapping is activated when
LED 1 lights up.
1TC STANDARD with TC – STANDARD mapping with trac-
tion control is activated when LED 1 and TC light up.
2 ADVANCED – ADVANCED mapping is activated, when
LED 2 lights up.
2TC ADVANCED with TC – ADVANCED mapping with trac-
tion control is activated when LED 2 and TC light up.
Warning
Voiding of the government approval for road use and the
insurance coverage If the combination switch is mounted,
the vehicle’s road permit, if any, expires.
– Only operate the vehicle in closed-off areas remote
from public road traffic if the combination switch is
installed.
The engine characteristic can be changed using button MAP on the
combination switch.
The traction control can also be activated via the combination
switch.
6.12 Overview of indicator lamps (All EU models)
V01752-10
Possible states
The high beam indicator lamp lights up blue – The
high beam is switched on.
Malfunction indicator lamp lights up/flashes yellow
– The OBD has detected an error in the vehicle elec-
tronics. Come safely to a halt, and contact an autho-
rized KTM workshop.
The fuel level warning lamp lights up yellow – The
fuel level has reached the reserve mark.
Turn signal indicator lamp flashes green – The turn
signal is switched on.
6.13 Overview of indicator lamps (XCF‑W)
V01751-10
Possible states
Malfunction indicator lamp lights up/flashes yellow
– The OBD has detected an error in the vehicle elec-
tronics. Stop and contact an authorized KTM work-
shop.
The fuel level warning lamp lights up yellow – The
fuel level has reached the reserve mark.
