MAINTENANCE WORK ON THE CHASSIS 32
10.13Dismounting the start number plate
700466-01
– Remove screw and take off clamp.
– Remove screw . Remove the start number plate.
10.14Installing the start number plate
700467-01
– Position the start number plate with the drill holes onto the holding lugs of the
fender.
700468-01
– Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Position the brake line. Put the clamp on, mount and tighten screw .
10.15Dismounting the front fender
700479-10
– Remove screws . Remove the front fender.
10.16Installing the front fender
700480-01
– Position the fender with holding lugs into the drill holes on the start number
plate.
