MAINTENANCE WORK ON THE CHASSIS 35
700512-01
– Remove screw .
– Remove screw .
700513-10
– Pull the main silencer off of the manifold at the rubber sleeve .
10.23Installing the main silencer
700513-01
– Position the main silencer.
– Mount the main silencer with the rubber sleeve .
– Mount the silentblock with the screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
700512-10
– Position the collar sleeves.
– Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
10.24Changing the glass fiber yarn filling of the main silencer x
Warning
Danger of burns The exhaust system gets very hot when the vehicle is driven.
– Allow the exhaust system to cool down. Do not touch hot components.
Info
Over a period, the fibers of the insulating material vanish into the air, and the silencer "burns out".
Not only is the noise level higher, the performance characteristic changes.
– Remove the main silencer. ( p. 34)
