PERIODIC SERVICE80
BAdjusting Front Axle Pivot [4WD]
To avoid personal injury:
A Park the tractor on a flat place.
A Lower the implement, lock the parking brake
and stop the engine.
If the front axle pivot pin adjustment is not correct, front
wheel vibration can occur causing vibration in the steering
wheel.
C Adjusting procedure
Loosen the lock nut, and tighten the adjusting screw so
that the oscillating load is 50 to 100 N (5.1 to 10.2 kgf, 11.2
to 22.5 lbf). (If the adjusting screw is tightened, loosened
and retightened, apply liquid gasket to its tip.) Retighten
the lock nut.
Consult your local KUBOTA Dealer for further details.
BReplacing Fuel Filter Element
(See "Cleaning Fuel Filter" in "EVERY 100 HOURS" in
"PERIODIC SERVICE" section.)
BChanging Front Axle Case Oil
1. Park the tractor on a firm, flat and level surface.
2. To drain the used oil, remove the right and left drain
plugs and filling plug at the front axle case and drain
the oil completely into the oil pan.
3. After draining, reinstall the drain plugs.
4. Fill with new oil up to the upper notch on the dipstick.
(See "LUBRICANTS" in "MAINTENANCE" section)
A After 10 minutes, check the oil level again; add oil to
prescribed level.
5. After filling, reinstall the filling plug.
6. Properly dispose of used oil.
EVERY 800 HOURS
BAdjusting Engine Valve Clearance
Consult your local KUBOTA Dealer for this service.
EVERY 1 500 HOURS
BChecking Fuel Injection Nozzle Injection
Pressure
Consult your local KUBOTA Dealer for this service.
EVERY 3 000 HOURS
BChecking Injection Pump
Consult your local KUBOTA Dealer for this service.
BChecking Turbocharger
[B3350/B3350SU only]
Consult your local KUBOTA Dealer for this service.
(1) Adjusting screw
(2) Lock nut
Oil capacity 4.7 L (5.0 U.S.qts.)
(1) Filling plug with dipstick
(2) Drain plug
(A) Oil level is acceptable
within this range
To Next Page
