63PERIODIC SERVICE
PERIODIC SERVICE
HOW TO OPEN THE HOOD
To avoid personal injury from contact with moving
parts;
A Never open the hood or engine side cover while
the engine is running.
A Do not touch muffler or exhaust pipes while
they are hot; Severe burns could result.
A Support hood with other hand while unlocking
support link.
BHood
C Open the hood
1. To open the hood, twist the mascot.
2. Open the hood by holding its bottom with both hands.
3. Hold the hood and insert the support rod to the
mounting hole.
C Close the hood
1. To close the hood, hold the hood and release the
support rod.
2. In closing the hood, use both hands again.
(1) Mascot
(2) Hood
(A) "TWIST"
(A) "OPEN"
(1) Hood
(2) Mounting hole
(3) Support rod
(A) "INSERT"
(A) "CLOSE"
To Next Page
