31OPERATING THE TRACTOR
BHead Light / Turn Signal / Hazard Light
Switch
C Head Light Switch
(A) OFF....Head light OFF.
(B) .....Head light ON.
C Hazard Light
1. When hazard light switch is pushed, the hazard lights
flash, along with the L/H and R/H indicators on the
instrument panel.
2. Push hazard light switch again to turn off the hazard
lights.
C Turn Signal with Hazard Light Switch On.
1. To indicate a right turn with the hazard lights already
flashing (hazard switch on), turn the turn signal switch
clockwise.
2. To indicate a left turn with the hazard lights already
flashing, turn the turn signal switch counterclockwise.
3. When the left or right turn signal is activated in
combination with the hazard lights, the indicated
turning light will flash and the other will stay on.
C Turn Signal with Hazard Light Switch Off
1. To indicate a right turn without hazard lights (hazard
switch off), turn the turn signal switch clockwise.
2. To indicate a left turn without hazard lights, turn the
turn signal switch counterclockwise.
3. When the left or right turn signal is activated without
the hazard lights, the indicated turning light will flash
and the other will stay on.
A The hazard light switch is operative when the key
switch is in either the "ON" or "OFF" positions.
A The turn signal light switch is only operative when the
key switch is in the "ON" position.
A The indicator in the hazard light switch will light up
when the head light switch is turned on.
A Be sure to return the turn signal switch to center
position after turning.
2. Selecting light switch positions.
(1) Turn signal light switch
(2) Head light switch
(3) Hazard light switch
(4) Hazard / Turn signal indicator
(1) Head light switch
(2) Turn signal light switch
(A) "OFF"
(B) "ON"
