OPERATING THE TRACTOR30
C Armrest angle adjustment
The armrest angle can be adjusted by the hex socket
head cap bolts (socket size 7/32 inch).
[B3350SU]
C Position adjustment
Pull in the position adjust lever and slide the seat
backward or forward, as required. The seat will lock in
position when the lever is released.
A After adjusting the operator's seat, be sure to check
that the seat is properly locked.
BSeat Belt
To avoid personal injury:
A Always use the seat belt when the ROPS is
installed.
A Do not use the seat belt if a foldable ROPS is
down or there is no ROPS.
Adjust the seat belt for proper fit and connect to the
buckle. The seat belt is auto-locking retractable type.
BTilt Steering Adjustment
[B2650/B3350 only]
To avoid personal injury:
A Do not adjust the steering wheel while the
tractor is in motion.
Press down the steering wheel pedal, to release the lock
so the steering wheel can be adjusted to one of three
desired positions.
(1) Hex socket head cap bolt
(2) Armrest
(1) Seat
(2) Position adjust lever
(A) "PULL IN"
(1) Seat belt
(1) Steering wheel tilt pedal (A) "PRESS DOWN"
