6 SPECIFICATIONS OF THE LOADER
OPERATIONAL SPECIFICATIONS
LOADER MODEL LA240
TRACTOR MODEL BX24
LIFT CAPACITY (BUCKET BOTTOM MID POINT) kg (lbs.) 240 (529)
U LIFT CAPACITY (BUCKET PIVOT PIN, MAX. HEIGHT) kg (lbs.) 340 (750)
V LIFT CAPACITY (500 mm FORWARD, MAX. HEIGHT) kg (lbs.) 235 (518)
W LIFT CAPACITY (BUCKET PIVOT PIN, 1500 mm HEIGHT) kg (lbs.) 375 (827)
X LIFT CAPACITY (500 mm FORWARD, 1500 mm HEIGHT) kg (lbs.) 270 (595)
Y BREAKOUT FORCE (BUCKET PIVOT PIN) N (lbs.) 6290 (1415)
Z BREAKOUT FORCE (500 mm FORWARD) N (lbs.) 4410 (992)
VV BUCKET ROLL-BACK FORCE AT MAX. HEIGHT N (lbs.) 4750 (1069)
XX BUCKET ROLL-BACK FORCE AT 1500mm HEIGHT N (lbs.) 5600 (1260)
ZZ BUCKET ROLL-BACK FORCE AT GROUND LEVEL N (lbs.) 5490 (1235)
RAISING TIME sec. 3.5
LOWERING TIME sec. 2.7
BUCKET DUMPING TIME sec. 1.7
BUCKET ROLLBACK TIME sec. 2.4
