U20-3, U25-3 WSM Machine body (Mechanism section)
II-M-3
b. Main dimensions
(A) (B) (C) (D) (E) (F) (G) (H) (I) (J) (K) (L) (M) (N) (O) (P) (Q) (R) (S) (U)
590 620
1400
[1300/1500]
710
(760)
1300
1400
[1300/1500]
3970
(3650)
2610
(2320)
2320 1900
1780
(1940)
2380
(2360)
320
[330]
440
[280]
2920 930 3850 4030 4140 800
U20-3
CANOPY
590 620 1500 760 1300 1500
4400
(4160)
3020
(2790)
2550 2300
1790
(1940)
2420
(2400)
360 320 3110 990 4100 4400 4510 800
U25-3
CANOPY
(
Cabin type models
) [
Track width changes models
]
mm
