12. COOLING SYSTEM
12-4
G-DINK 300i
Inspect the radiator soldered joints and
seams for leaks.
Blow dirt out from between core fins with
compressed air. If insects are clogging the
radiator, wash them off. Carefully
straighten any bent fins.
RADIATOR REMOVAL
Drain the coolant.
Disconnect the outlet tube of the reserve
tank.
Remove the overflow tube clamp and
disconnect the overflow tube.
Disconnect the air vent tube from the
radiator filler.
Disconnect the fan motor wire coupler.
Loosen the hose band and disconnect the
upper hose and lower hose from the
radiator.
Disconnect the thermostatic switch wire
coupler.
Thermostatic Switch
To Next Page
