13. FUEL INJECTION SYSTEM
13-20
G-DINK 300i
ELECTRIC CONTROL UNIT
(ECU)
REMOVAL/INSTALLATION
Disconnect the ECU connector and remove
the ECU from the frame.
Installation is in the reverse order of the
removal.
● Do not disconnect or connect the ECU
connector during the ignition switch
“ON”; it may cause the ECU damaged.
● The throttle position sensor (TPS) and
idle air bypass valve (ISC) have to be
reset when throttle body, MAP, TPS,
ISC or ECU has been reinstalled.
Speedometer
Radiator Filler Cap
Ignition Switch
ECU
Horn
Coolant Reserve Tank
To Next Page
