14. HANDLEBAR/FRONT WHEEL/FRONT BRAKE/
FRONT SHOCK ABSORBER/STEERING STEM
14-13
G-DINK 300i
FRONT SHOCK ABSORBER
REMOVAL
Remove the front cover and front fender.
Remove the front brake caliper
Remove the front wheel
Remove the speed wheel sensor bolt and then
remove the brake hose guide from right front
shock absorber.
Remove two mounting bolts and then remove
the right/left front shock absorber.
INSTALLATION
Installation is in the reverse order of removal.
INSPECTION
Inspect the following items and replace if
necessary.
•Front shock absorber tube bending, damage
or wear
•Weak front shock absorber spring
•Damper and damper rod bending
•Oil seal damage or wear
Tighten the shock absorber mounting
bolt to the specified torque.
Torque: 2.7 kgf-m (27 N-m, 19.5 lbf-ft)
