1. GENERAL INFORMATION
1-21
MXU 500
CABLE & HARNESS ROUTING
Remove the fuel tank and fuel valve
together (refer to the “FUEL TANK”
section in the chapter 5).
＊
Remove the front cooling duct (refer to
the “ENGINE REMOVAL” section in
the chapter 7).
＊
Remove the rear cooling duct (refer to
the “ENGINE REMOVAL” section in
the chapter 7).
＊
