3. INSPECTION/ADJUSTMENT

3-2

MXU 500

Tire pressure

1 Rider

Front 0.28 kgf/cm² (28 Kpa, 3.2 psi)

Rear 0.28 kgf/cm² (28 Kpa, 3.2 psi)

Tire size:

Front : 25X8-12

Rear : 25X10-12

TORQUE VALUES

Spark plug 1.2kgf-m (12 N-m, 8.6 lbf-ft)

Tappet ADJ nut 0.9 kgf-m (9 N-m, 6.5 lbf-ft)

Engine oil filter cap 1.5 kgf-m (15 N-m, 11 lbf-ft)

Engine oil filter cartridge 1 kgf-m (10 N-m, 7.2 lbf-ft)

Engine oil drain plug 2.5 kgf-m (25 N-m, 18 lbf-ft)

Rear drive gear oil drain bolt 2 kgf-m (20 N-m, 15 lbf-ft)

Rear drive gear oil level check bolt 2 kgf-m (20 N-m, 15 lbf-ft)

Rear drive gear oil filler cap 1.5 kgf-m (15 N-m, 11 lbf-ft)

Front drive gear oil drain bolt 3.2 kgf-m (32 N-m, 23 lbf-ft)

Front drive gear oil filler cap 3.5 kgf-m (35 N-m, 25.5 lbf-ft)

Front drive gear oil level check bolt 1 kgf-m (10 N-m, 7.2 lbf-ft)

Tie-rod adjusting nut 3.5 kgf-m (35 N-m, 25.2 lbf-ft)

Front wheel hub nut 7 kgf-m (70 N-m, 50 lbf-ft)

Rear wheel hub nut 10 kgf-m (100 N-m, 72 lbf-ft)

SPECIAL TOOLS

Valve adjusting wrench A120E00036

Oil cartridge wrench A120E00061
