KYMCO MXU 500 User Manual

3. INSPECTION/ADJUSTMENT
3-28
MXU 500
3. Loosen the lock nuts (3) of rod (4).
4. Remove the bolt and nut from the rod
end (shift arm side).
5. Shift the drive select lever to neutral
along the shift guide.
6. Shift the gear to neutral by moving the
shift arm (The neutral indicator lamp
comes on.)
Bolt/Nu
t
Shift Ar
m
