16. BRAKE SYSTEM
16-18
MXU 500
4. Remove the brake fluid reservoir cap
(brake pedal).
5. Connect a transparent hose to the front
brake caliper bleed valve (front right and
left calipers) and then loosen the bleed
valve nut. Use a syringe to draw the
brake fluid out through the hose. Then
tighten the bleed valve nuts.
Torque: 0.6 kgf-m (6 Nm, 4.32 lbf-ft)
6. Connect a transparent hose to the rear
brake caliper bleed valve (combined) and
then loosen the bleed valve nut. Use a
syringe to draw the brake fluid out
through the hose. Then tighten the bleed
valve nut.
Torque: 0.6 kgf-m (6 Nm, 4.32 lbf-ft)
Use shop towels to cover plastic parts
and coated surfaces to avoid damage
caused by splash of brake fluid.
＊
Cap Reservoi
