16. BRAKE SYSTEM
16-33
MXU 500
INSTALLATION
Install and tighten the mounting bolts to the
specified torque.
Torque: 1.2 kgf-m (12 Nm, 8.6 lbf-ft)
Install the all brake fluid hoses with the
attaching bolts and new sealing washers,
then tighten the bolts to the specified torque.
Torque: 3.5 kgf-m (35 Nm, 25 lbf-ft)
Fill the specified brake fluid and bleed air
from the brake system (refer to the
“COMBINATION BRAKE FLUID
CHANGE/AIR BLEED (ON ROAD)”
section in this chapter).
