KYMCO X-Town 300 User Manual

SECURITY SHUTTER
CONTROLS & FEATURES
To open the ignition switch security
shutter :
Push the shut button on the ignition switch
panel to close the security shutter.
To shut the ignition switch security
shutter :
Insert the specific key until the notch is
aligned with the pin .
Turn clockwise to open the security shutter.
The keys have a unique code that is stamped on
the tab with the keys. This code is required if you
need to duplicate the key. Record this important
code on the blank column below.
Security shutter key code:
1
2
2
3
2

KYMCO X-Town 300 Specifications

General

Cooling System	Liquid cooled
Maximum Torque	22.5 Nm @ 6500 rpm
Transmission	CVT
Front Suspension	Telescopic fork
Rear Suspension	Dual shocks
Front Brake	Disc
Rear Brake	Disc
Front Tire	120/70-15
Seat Height	800 mm
Width	800 mm
Fuel Capacity	12.5 Liters
Engine Type	4-stroke, single cylinder
Fuel System	Electronic Fuel Injection
