2RV/2RW/2RX/2RY/3RA-3
7-112
(6) Abnormal sound from the primary paper feed section
The primary feed section is worn down, dirty, not attached properly or foreign objects adhere to it
(7) Abnormal sound from the machine front side
The MP feed section is worn down, dirty, not attached properly or foreign objects adhere to it
2 Cleaning and applying the
grease
The shaft is dirty or foreign
objects adhere to it.
Clean the upper exit pulley
and apply grease to it.
3 Cleaning and applying the
grease
The FD guide shaft is dirty
or foreign objects adhere
to it.
Clean the FD guide shaft and
apply grease to it.
Step Check description Assumed cause Measures Reference
1 Checking the gear and the
clutch
The parts such as the gear
or the clutch are not prop-
erly attached.
Reattach the primary paper
feed drive parts such as the
gear or the clutch if they are
not properly attached.
2 Cleaning and applying the
grease
The gear, bushing, etc. are
dirty or foreign objects
adhere to them.
Clean the primary paper feed
drive parts such as the gear
or the bushing and apply the
grease to them.
3 Cleaning and applying the
grease
The shaft or the bushing is
dirty or foreign objects
adhere on them.
Clean the shaft and the bush-
ing of the paper feed roller
and apply grease to them.
Step Check description Assumed cause Measures Reference
1 Checking the gear and the
clutch
The parts such as the gear
or the clutch are not prop-
erly attached.
When the gears or the clutch
in the MP paper feed drive
section are not properly
attached, reattach them.
2 Cleaning and applying the
grease
The shaft or the bushing is
dirty or foreign objects
adhere on them.
Clean the shaft and the bush-
ing of the MP paper feed
roller and apply the grease to
them.
3 Checking the MP separa-
tion pad
The MP separation pad
surface is dirty or worn
down.
Clean the MP separation pad.
Then, replace it if necessary.
4 Checking the MP bottom
plate
The MP bottom plate is not
properly attached.
Reattach the MP bottom
plate.
Step Check description Assumed cause Measures Reference
To Next Page
