Variable Curvature WST systems presets
Variable Curvature WST systems presets
The factory presets dedicated to variable curvature WST line sources are optimized for long throw applications. In the
following sections, tables describe the loudspeaker congurations and the factory presets for each system. Discriminant
acoustic properties of each loudspeaker conguration are given, such as -10 dB bandwidth or LF limit, frequency
response contour, or directivity specicity.
K1
Compatibility issues
[K1], [KARADOWNK1] and [K2 xxx] presets from versions 4.x and later of the preset library are not compatible
with [K1] and [KARADOWNK1] from versions of the preset library prior to 4.0.
Compatibility issues may occur when working from a Session le with units using older presets. Use the same
version of the preset library for all units within a single line source.
preset(s)
loudspeaker
conguration
K1 K1-SB KS28 or SB28*
acoustic properties
K1 line source [K1] — 35 Hz - 20 kHz
K1 / K1-SB line
source (K1-SB on top)
[K1] [K1SB_X] — enhanced LF throw
K1 line source +
coupled K1-
SB subwoofers
(beside or behind)
[K1] [K1SB_60] —
down to 30 Hz
reinforced LF contour
LF rejection (side
polarized or
rear cardioid)
K1 line source +
subwoofers
[K1] — [xx28_60]
down to 25 Hz
reinforced LF contour
* with subwoofers as a cardioid array, use [xx28_60_C] or [xx28_60_Cx]
Downll options for additional vertical coverage
K2 enclosures driven by [K2 110].
Kara enclosures driven by [KARADOWNK1] or Kara II enclosures driven by [KARAIIDOWNK1].
[K1] and [K2 xxx]
loudspeaker elements outputs channels routing gain delay polarity mute
left LF OUT 1 LF ON
right LF OUT 2 LF ON
MF OUT 3 MF ON
HF OUT 4 HF
IN A 0 dB 0 ms +
ON
left/right when looking at the front face of the enclosure
32 Preset Guide owner's manual (EN) version 16.0
